Booster RA

HIGH PRECISION - FAST REVERSALS - FREQUENT to permanent ACCELERATION

BOOSTER RA is a high-performance, right-angle low-backlash planetary gearbox. It delivers high acceleration and fast reversals to heavy duty  servo-applications.

Acceleration capacity ++++
Fast reversals ++++
Radial load rating +++
Axial load rating +++
Stiffness ++++
Precision ++
Economy ++++
Suitable for servo applications YES
Number of sizes in the line 3 (from 60 to 120)
Angular backlash 8 arc-min
Interface (output side) Square
Output Shaft, with or without a key

ImprimerTélécharger le pdf

INTERNAL CONSTRUCTION

Booster RA is a high-performance, helical planetary gearbox.



  • The planet carrier is a cage, to provide stiffness and acceleration capacity. It is monobloc with the output shaft.
  • The cage is centered inside the 1-piece inner planetary ring by means of 2 angular-contact ball-bearings. This construction improves acceleration capacity and acceptance of high torque variations.
  • The planetary ring is monobloc with the housing and the output flange, to provide maximum rigidity to fast-reversals applications.
  • We recommend this line for applications using application factor Ka<1.85 (refer to the information section for more details about application factors). For even greater application factors we recommend using a rotating output flange, as in the Ultimate line.


Right-angle high precision planetary gearbox

  • The right-angle transmission is handled by carburized and quenched, spiral-bevel gears made of premium Japanese steel, to offer long-lasting precision and acceptance of high fluctuations of torque or fast reversals.
  • The motor shaft connection is a balanced coupling, so the efforts on your motor bearings are minimal.
  • Installation is fast and easy thanks to a 1-screw lock to your motor shaft.
  • The input flange features weight reduction.
  • The gearbox will be delivered with the adapting flange corresponding to your motor.

LINE FEATURES

QUIET AND SAFE OPERATION

Like all ReckonTM products, the "BOOSTER RA" line follows the Perfect PitchTM concept, including the use of helical toothing to provide quiet operation to your drive.

LONG-LASTING PRECISION

High-precision planet gears in Japanese carburized and quenched steel allow high torque density and strong accelerations, year after year, without loss of precision.

HIGH PERFORMANCE DESIGN

The planet carrier is a cage, to provide high torsional stiffness.

It is strongly supported by 2 preloaded angular-contact ball-bearings (small sizes) or taperred rollers bearings, to ensure the perfect alignment of the gears, even at maximum torque, as well as high acceptance of radial and axial forces.

HIGH TORSIONAL STIFFNESS

The planetary ring is monobloc with the external housing and the output flange, to provide high rigidity to your fast-reversals applications.

HIGH PERFORMANCE RIGHT-ANGLE STAGE

All Reckon righ-angle gearboxes use high-precision, carburized and quenched, spiral-bevel gears in premium japanese steel

Spiral-bevel gears are known for their quiet operation, carburizing and provides hardness, so your gearbox does not lose precision with time, even in tough operating conditions.

TECHNICAL DATA




Ratio

BOOSTER RA

60

BOOSTER RA

90

BOOSTER RA

120

BOOSTER RA

140

BOOSTER RA

180

T2n(1) (Nm)

(1 stage)

1/10

16

47

125

200

520

1/9

17

53

127

270

580

1/8

24

71

156

290

625

1/7

24

73

150

290

640

1/6

24

73

163

305

645

1/5

27

73

150

315

710

1/4

17

73

145

220

610

1/3

16

47

130

220

460

T2n (Nm)

(2 stages)

1/100

16

47

125

200

520

1/80

24

71

156

290

625

1/50

27

73

150

315

710

1/25

27

73

150

315

710

1/20

17

73

145

220

610

1/15

16

47

130

220

460

Acceleration torque Tmax(2)

2*T2n

Emergency stop torque Tx(3)

3*T2n

Standard Angular backlash

(arc-min)

1 stage

< 8

2 stages

< 8

Nominal input speed(4) (rpm)

3,000

3,000

3,000

2,500

2,000

Maximum input speed(5) (rpm)

6,000

6,000

6,000

5,000

4,000

Maximum radial load(6) (N)

1,200

2,450

4,400

9,000

14,500

Maximum axial load (N)

1,050

2,200

4,000

8,300

13,500

Efficiency (7) (%)

1 stage

>96

2 stages

>93

Torsional stiffness (N/arc-min)

7

14

25

50

145

Nominal lifetime (8) (hours)

20,000

Nominal / min / max operating temp.(9) (°C)

20 / -10 / +45

Max housing temp. (°C)

90

Protection class

IP65

Noise level(10) (dB)

<68

Lubricant

Sumico grease (lubricated for life)

Color

Capri blue (RAL 5019)

Input flange

Aluminum

(1)     : Nominal output torque.
(2)     : Torque which is necessary to start the application, applicable 2,000 hours.
(3)     : 100 occurrences maximum.
(4)     : Speed at which the nominal torque is applicable 20,000 hours.
(5)     : Peak speed only.
(6)     : Applied at the middle of the output shaft at 300 rpm.
(7)     : Measured at full load and at 25°C
(8)     : Lifetime at nominal torque and speed. Consult us to obtain a free estimation of lifetime in your working conditions
(9)     : Room temperature. Refer to temperature factors in dedicated section.

DOWNLOAD AREA

2D drawings (pdf) 3D view (pdf)* 3D drawings (Step)
BOOSTER-SQ-RA-060 - 2 stage - ratios 3 to 10 BOOSTER RA  construction

3D Step files differ from motor to motor and cannot be downloaded from the website.

They will be sent to you upon request, within 24h.

BOOSTER-SQ-RA-060- 2 stages - ratios 12 to 100
BOOSTER-SQ-RA-090 - 1 stage - ratios 3 to 10
BOOSTER-SQ-RA-090 - 2 stages - ratios 12 to 25
BOOSTER-SQ-RA-090 - 2 stages - ratios 30 to 100
BOOSTER-SQ-RA-120 - 1 stage - ratios 3 to 10
BOOSTER-SQ-RA-120 - 2 stages - ratios 12 to 30
BOOSTER-SQ-RA-120 - 2 stages - ratios 35 to 100

Booster RA of sizes above 120 cannot be downloaded from the website will be sent individually.

Do not hesitate to contact us in case of question or doubt. Additional drawings are available upon request.

*To view the 3D pdf file, save the file first and open it with Acrobat as your web browser might not enable 3D views. You will need to enable the 3D view in Acrobat reader when asked. Click and drag your mouse to discover the gearbox construction. You can zoom in and out, and right-click to hide components and see what's behind them. Enjoy!
